A distribution transformer runs for 30–40 years. Its biggest environmental footprint isn't how it's built — it's the energy it loses every hour of every one of those years. That's where we focus.
We're an independent supplier, not a greenwasher — so our sustainability story is deliberately narrow and honest. For a transformer, the numbers that matter most aren't in the brochure; they're the kilowatts quietly lost as heat, hour after hour, for the life of the asset.
That's why every distribution unit we supply is built to EU EcoDesign Tier 2 — the current minimum-efficiency law for no-load and load losses. Lower losses cut energy bills, carbon and grid strain in the same stroke.
Around that core we add cleaner insulation options, a retrofit-before-replace service, recyclable materials, and operations managed under ISO 14001.
A representative 1,000 kVA unit, compared against a pre-EcoDesign design. Tier 2 mostly attacks no-load loss — the energy burned whenever the transformer is simply energised.
Annual energy lost — MWh / year, per 1,000 kVA unit
| Design | No-load loss (MWh/yr) | Load loss (MWh/yr) | Total (MWh/yr) |
|---|---|---|---|
| Legacy design | 14.9 | 18.2 | 33.1 |
| EcoDesign Tier 2 | 6.7 | 12.6 | 19.3 |
Illustrative comparison for a representative 1,000 kVA distribution transformer energised 8,760 h/year at ~40% average loading. Legacy figures reflect typical pre-EcoDesign designs; Tier 2 figures reflect the no-load and load-loss limits of EU Regulation 548/2014 (Tier 2, in force since July 2021). CO₂ estimated at 0.35 t per MWh. Actual figures depend on rating, loading and local grid mix.
Every distribution transformer we supply meets EU EcoDesign Tier 2 limits for no-load and load losses (Regulation 548/2014). Lower losses mean less wasted energy every hour of a 30–40 year life — the single biggest lever we have.
Biodegradable ester (K-class) fluid is available where fire safety or the environment demands it, and our cast-resin range is dry-type — oil-free, with no leak or fire risk for indoor and public sites.
See cast resin transformersOur revision and retrofit service brings older transformers up to current Tier 2 efficiency — rewinding, oil replacement and reassembly — extending the life of an existing asset instead of scrapping it.
Explore our servicesCore steel, copper windings and tank steel are highly recyclable. We manage and continually reduce the environmental impact of our operations and products under an ISO 14001 environmental management system.
Keeping a transformer fleet healthy means site visits, commissioning and inspections. We run ours from fully electric VW ID. Buzz Cargo vans — zero-emission mobility supporting projects across the Netherlands and Germany.
It's a small fleet and we won't overstate it — but aligning our own logistics with the energy transition we supply into is simply consistent.
Read the story
We only surface credentials we actually hold. Environmental performance is governed by ISO 14001; efficiency by EU EcoDesign; quality and safety by ISO 9001, IEC 60076 and VCA.
Specify it efficient
Tell us your rating, voltage and loading — we'll quote low-loss units that pay back over their whole life, not just on day one.
Start your project
Get an indicative budget price in three fields, or a full formal quote — valid for 30 days. We typically respond within one business day.
